Fluke i30s AC/DC PINCE AMPEREMETRIQUE

Specifications Specified current range 30 mA to 30A dc, 30 mA to 20 A ac rms Usable current range 5 mA to 30 A dc, 30 mA to 20 A ac rms Crest Factor 1.4″ Output sensitivity 100 mV/A Accuracy (at 25 °C) ± 1 % of reading ± 2 mA Resolution ± 1 mA Load impedance > 100 kΩ Conductor position sensitivity ± 1 % relative to center reading Frequency range DC to 100 kHz (- 0.5 dB) Phase shift below 1 kHz < 2 degrees Temperature coefficient ± 0.01 % of reading/°C Power supply 9 V Alkaline, MN1604/PP3, 30 hours, low battery indicator Working voltage (see Safety Standards section) 300 V ac rms or dc Maximum conductor size 19 mm diameter Output connection Safety BNC connector, supplied with safety 4 mm adapter Output zero Manual adjust via thumbwheel Cable length 2 meters Operating temperature range 0 °C to 50 °C Storage temperature range (with battery removed) -20 °C to 85 °C Operating humidity 15 % to 85 % (non-condensing) Weight 250 g
